Inshine EP803
Product Features
It has good cutoff function in the ultraviolet band (290-380), ensuring the anti UV ability of the component. It can convert the light in the UV band to other bands, improving the photoelectric efficiency of the component.
Product characteristics
Test items
unit
Referenced
standards
Specification value
Wide in width
mm
GB/T 13542.2-2009
≥ standard value（0-+5）
Weight in grams
g/m2
ISO 536-2012
≥ standard value
Tensile strength（MD）
MPa
GB/T 13542.2-2009
≥10
Tensile strength（TD）
MPa
GB/T 13542.2-2009
≥10
Elongation at break（MD）
%
GB/T 13542.2-2009
≥400
Elongation at break（TD）
%
GB/T 13542.2-2009
≥400
Heat shrinkage rate（120℃×3min）MD
%
GB/T 13542.2-2009
≤3.0
Heat shrinkage rate（120℃×3min）TD
%
GB/T 13542.2-2009
≤0.5
EVA and glass Peel Strength
N/cm
GB/T 2790-1995
≥60
EVA and cell peel strength
N/cm
GB/T 2790-1995
≥40
Transmittance（380-1100nm）
%
T/CPIA0004-2017
≥90
Transmittance（290-380nm）
%
T/CPIA0004-2017
<30
Volume resistivity
Ω·cm
GB/T 1410-2006
≥1×1015
Anti migration performance (105 ℃, 96h migration width)
cm
<0.2
Crosslinking degree (xylene method)
%
GB/T 29848-2013
75-95
Constant damp heat test
85℃×85%RH 1000H
Yellowing index△YI
--
IEC 61215-2 2016
≤3.0
Peel strength with glass
N/cm
≥40
UV aging resistance test
120KWH/m2
Yellowing index△YI
--
IEC 61215-2 2016
≤3.0
Peel strength with glass
N/cm
≥40
PCT high temperature and high
humidity experiment
48h
Yellowing index△YI
--
T/CPIA0004-2017
≤3.0
Peel strength with glass
N/cm
≥40
